DDR4
過酷な環境下での使用を想定した特別仕様。
Code ddr4
CTR 383
- FEATURES
- ‧JEDEC Standard 1.2V+/-0.06V Power Supply
- ‧VDDQ = 1.2V+/-0.06V
- ‧VPP = 2.5V (2.375V to 2.75V)
- ‧VDDSPD = 2.5V +/-10%
- ‧Operating Temperature
- TCASE = 0°C to +85°C for Commercial Temp Grade
- TCASE = -40°C to +95°C for Industrial Temp Grade
- ‧Data Transfer Rates
- Up to PC4-3200
- ‧8-bit pre-fetch
- ‧Bi-Directional Differential Data Strobe
- ‧On Die Termination using ODT pin
- ‧Temperature sensor with integrated SPD
- ‧Burst Length (BL) switch on-the-fly BL8 or BC4 (Burst Chop)
- ‧Temperature sensor with integrated
- ‧RoHS compliant (Lead-free)
- ‧Conformal Coating and BGA underfill are available upon request
- BENEFITS
- ‧Long term supply
- ‧Locked BOM support
- ‧High quality
- ‧100% system level testing
- ‧Technical support
